Searching Machines

Purpose

To practise systematizing code; preparation for interfaces.

Due Date

The completed lab assignment is due Friday, 2018-02-09 by the beginning of lecture.

Accepting

states

No

vowel

reject

A

Seen

I Seen

U

Seen

E

Seen

O

Seen

reset ‘a’ ‘e’

‘i’

‘o’

‘u’

other vowel

other vowel

other

vowel

other vowel

other vowel

vowel

non vowel

Figure 1: A Finite State Machine

Finite State Machines

Finite state machines are a theoretical machine studied in cpsc 242 and cpsc 340.

They are frequently useful for classifying and manipulating strings. For instance

when you ask a text editor to search for a pattern in a large file, it probably builds

a finite state machine to do so.

© 2018 David Casperson. This document may be

freely copied, provided that this copyright notice is

preserved.

UNBC CPSC 101

The finite state machine shown in Figure 1 on the preceding page is designed to

find “abstemious” words, that is, words where each vowel (’a’, ’e’, ’i’, ’o’, or ’u’)

occurs exactly once and in order.

A finite state machine has a certain fixed number of states (circles in Figure 1). When

the number of states is quite small, it makes a lot of sense to represent the state

type by an enum, for instance,

public enum State = { NoVowel, ASeen, /* … */ USeen, REJECT ; }

A finite state machine also has a special start state. We can code this as1

class Machine

1 public class Machine {

2 private State currentState ;

3

4 public void reset() { currentState = State.NoVowel ; }

5

6 public Machine() { reset() ; /* …. */ }

The arrows between states in a state machine diagram indicate what happens when

we are in a particular state and we read a particular character. In Figure 1, only some

of the lines are shown, as non-vowels leave the state unchanged.

Starting from the start state, the machine accepts characters one by one. Each time

it accepts a character, its state may change based on the transition lines. For the machine

shown in Figure 1 we can code this as

class Machine

10 public void acceptChar(char c) {

11 switch(c) {

12 /* … other cases */

13 case ‘e’:

14 currentState

15 = (currentState==State.ASeen) ? State.ESeen : State.REJECT ;

16 break ;

17 /* … other cases, default */

18 }

19 }

Some of the states are accepting states. If the machine is in an accepting state, then it accepts

the word that got it into that state. Note that it is possible to go from an accepting

state to a non-accepting state. For the machine shown in Figure 1 we can code this as

class Machine

8 public boolean isAccepting() { return (currentState==State.USeen) ; }

1Note that the coding style used in this lab handout is not my preferred style. In the interest of making

the code compact, I have used much less vertical white-space than I typically do.

Laboratory Assignment Searching Machines • 2

UNBC CPSC 101

Once we have a machine (say as a class variable somewhere) it is quite easy to write

a method to determine if a word is acceptable:

class Main

4 public /* static */ boolean isAbstemious(String s) {

5 machine.reset() ;

6 for (char c: s.toCharArray()) { machine.acceptChar(c) ; }

7 return machine.isAccepting() ;

8 }

9 }

⇒ Steal code from laboratory assignment 2, and write a complete program that finds all

of the “abstemious” words in a word list file. Use separate files for State.java and

Machine.java .

⇒ Use your program to find all of the “abstemious” words in /usr/share/dict/web2 ,

and print them to a file facetious.txt .

Larger Numbers of States

initial

State

stuck

State

‘c’

1

‘k’

2

reset ‘c’

‘k’

1

‘k’

‘k’

‘b’ ‘k’

‘k’

Figure 2: A Few of the States and Transitions for “Degenerative” words

Suppose that we want to find “degenerative” words, that is words that contain six or

more consonants, all in increasing order. For our purposes, consonants are letters that

are neither vowels, nor ‘y’. As above, a vowel is any one of ‘a’, ‘e’, ‘i’, ‘o’, or ‘u’.

We can also create a finite state machine for this problem, but the number of states

is quite large (minimally 7 × 20 + 2, see Figure 2). Here is makes a great deal of

sense to encode states as a class (State2).

Laboratory Assignment Searching Machines • 3

UNBC CPSC 101

The state of State2 can be encoded as

class State2

2 private boolean inInit ;

3 private boolean amStuck ;

4 private int consonantCount;

5 private char lastConsonant;

It’s helpful to name some special states:

class State2

7 public static State2 initialState = new State2(true,false,0,’@’) ;

8 public static State2 stuckState = new State2(false,true,0,’@’) ;

where somewhere there is a 4-argument constructor that sets the private variables to its

arguments.

Thinking ahead to creating a machine, we add helper methods to our class:

class State2

13 public State2 nextState(char c) {

14 if (amStuck || ! isConsonant(c)) return this ;

15 else if (inInit || c>lastConsonant)

16 return new State2(false,false,1+consonantCount,c) ;

17 else return stuckState ;

18 }

and

20 public boolean isAcceptingState()

21 { return (!amStuck && consonantCount>=6) ; }

and a helper method (needed in nextState)

10 private static boolean isConsonant(char c)

11 { return (“bcdfghjklmnpqrstvwxz”.indexOf(c,0)>-1) ; }

⇒ Complete the coding of the State2.

⇒ Now create a Machine2 class that has the same public methods as the Machine class, but

which uses a State2 member variable, and which isAccepting() of “degenerative”

words.

⇒ Following the previous pattern, write a complete program that finds all of the “degenerative”

words in a word list file.

⇒ Use your program to find all of the “degenerative” words in /usr/share/dict/web2 ,

and print them to a file demipriest.txt .

Laboratory Assignment Searching Machines • 4

UNBC CPSC 101

Lab 2 Revisited

Suppose that we try to build a finite state machine for Lab 2. One way to encode state is

as

class State3

2 private int pairCount;

3 private int maxPairCount;

4 private int lastCharCount;

5 private char lastChar;

However, there is something tricky about state transitions here. After we have read

“ggoobookkee” the state needs to be { pairCount = 2, maxPairCount= 2, lastCharCount=

2, lastChar=’c’}. That is, we cannot conclude that “. . . ee” is a pair until we see the following

character.

To accommodate this, we probably want to change the main program word test to

send a spurious extra character, something like

7 public boolean isBookkeeping(String s) {

8 machine.reset() ;

9 for (char c: s.toCharArray()) { machine.acceptChar(c) ; }

10 machine.acceptChar(’\u1f63b’) /* a smiling cat */;

11 return machine.isAccepting() ;

12 }

⇒ [Bonus] Recode the program from Lab assignment 2 to use a state and machine class as

suggested above, and test it on Finnish words, looking for 4 or more consecutive pairs.

Laboratory Assignment Searching Machines • 5
